Flexible chain conveyor lineIt's a device formaterial handlingIt consists of a series of bendable chain plates attached to a chain. These chain plates can move horizontally, vertically and diagonally, thus realizing material conveying and transferring.
One,flexographicchain conveyorcharacteristics
Multi-dimensional delivery capability:Complex paths such as straight-line conveying, climbing and lifting, 90° horizontal turns, and even 5°-90° vertical curves can be freely switched, with a minimum turning radius of only 150mm, making it easy to navigate through narrow workplaces.
Efficient and stable operation:Maximum conveying speed up to 50m/min, and in the transition of the curve needs to be reserved straight section buffer, to ensure that bottled beverages, boxed snacks and other products smooth transition, to prevent tipping and slipping.
Modular structure advantage:Conveyor beams with widths ranging from 45-300mm and single lengths of 3m can be quickly assembled like “building blocks” to form a 100-meter production line, which can be adapted to different production capacity requirements.
II. Main advantages
Flexible layout design
act asmodular designthe paradigm of theFlexible chain plate lineComposed of independent parts, it has simple and lightweight structure, convenient assembly and easy maintenance. It can flexibly adjust the conveying line according to the layout of the food production workshop and the change of the production process, easily realizing horizontal, inclined, turning and other multi-level and multi-angle conveying to meet the diversified production needs of food enterprises.
Quality materials and performance
The chain plate is made of high quality material with good wear and corrosion resistance, flat and smooth conveying surface and low friction. This makes it able to ensure the smoothness of conveying when conveying column-shaped tray cups, various bottles and box products without causing damage to the products, ensuring the integrity and safety of food in the conveying process, which is widely used in the industries of food and beverage, daily chemicals, pharmaceuticals, automobile parts, etc. While the food industry has very high requirements for the stability of conveying equipment, this quality of flexible chain plate line fits this demand.
Three,Reasons for the wide range of applications in the food industry
1.Clean and environmentally friendly, in line with food industry standards
The food industry has extremely strict hygiene requirements for the production environment, and theFlexible chain plate lineIt is assembled with white high-strength engineering plastic chain plate and anodized aluminum alloy frame, the chain plate is pure white, non-corrosive, non-rusting, no need for lubrication, avoiding oil contamination, and in full compliance with GMP specification. This provides a clean and safe conveying environment for food production, effectively prevents food from being contaminated during conveying, and guarantees the quality and safety of food.
2.Quiet operation to minimize noise disturbance
In food production plants, especially in noise-sensitive areas, the quietness of the working environment also affects productivity and employee performance.Flexible chain plate lineOperating sound is less than 30 dB, which is close to the library ambient noise standard, and the noise level is so low that there is virtually no noise disturbance to the work environment.
3.Stable and reliable conveying performance
Food products are often conveyed in a variety of shapes, sizes and weights, which places high demands on the stability and reliability of conveying equipment.Flexible chain plate lineThe chain plate is made of modified polyoxymethylene resin (POM) and the pin material is S5304 (stainless steel), which is durable and has a stable mechanical structure to ensure that the conveyed products do not fall over and slip, especially suitable for conveying precision parts, fragile products or liquid containers, which provides stable and reliable conveyance for food packaging and sorting, and effectively reduces the rate of loss of food products in the process of conveying.
