Line Shape

rectangles/ellipses

transmission method

leather belt

sprockets

connecting rod

Line length

≤5m

≤80m

≤10m

Line width

≤5m

≤10m

≤2m

diameter of a circular arc

159-1501mm

159-1501mm

159-1501mm

Slider spacing

100-3000mm

100-3000mm

100-3000mm

Slider movement time

≥0.8s

≥0.8s

≥0.1s

Secondary positioning time

≥0.3s

≥0.3s

≥0.3s

Single Slide Load

≤20kg

≤20kg

≤20kg

Repeat Positioning Accuracy

±0.05mm (with positioning mechanism)

±0.10mm (without positioning mechanism)
