Description
FVT2 - High Thrust Maglev Conveyor System
linear transport
(can be combined with other types of conveyor systems)
Circular runway conveyor
X-Y/Z conveying
(in combination with other types of conveyor systems in the return section)
mileage
- Open path, linear splicing, high degree of freedom
- Can be designed in a variety of configurations such as horizontal, vertical, belt hybrid, etc., and also supports the addition of turnouts.
- More combinations of coils and actuators for large load applications
- Can be combined with V-rail/T-rail/ball bearing/roller guide to achieve large loads.
- Can be used in combination with belt lines/multiple speed chain lines for more cost-effective conveying solutions
FVT2-Large Thrust Magnetic Drive Conveyor System
- Continuous Thrust. 800N
- Maximum thrust. 3700N (water-cooled) 2400N (naturally cooled)
- Maximum load . 300kg
- Maximum speed (m/min).1.8m/s
- Maximum acceleration. 1G
- Minimum centre distance of actuators : /
- Repeatable positioning accuracy : 1 ±0.01mm
